Lumistar MV threaded sight glasses — weldable, hygienic screwed sightglass assemblies compatible with DIN-11851; available in soda-lime or borosilicate glass with multiple gasket and alloy options.

Category:

Description

The Lumistar MV threaded sight glass is a robust, screwed sightglass assembly engineered for direct mounting into process vessels, tanks and pipelines using weldable threaded brackets. Designed in accordance with DIN-11864-1 and compatible with DIN-11851 style fittings, the MV series delivers reliable visual inspection for hygienic and industrial applications. Available in soda-lime or borosilicate glass and a range of gasket and ring materials to suit temperatures up to 280 °C.

Why choose a Lumistar threaded sight glasses MV?

Lumistar MV threaded sight glasses combine hygienic design with practical flexibility — ideal when you need a reliable, easy-to-install sighting solution for welded vessels and screwed fittings. The MV series features weldable threaded brackets for secure mounting, compatibility with DIN 11851 style fittings, and choice of soda-lime or borosilicate glass plus multiple gasket/O-ring materials to match your temperature, chemical and CIP requirements.

Product at a glance

  • Standard: Lumistar threaded sight glasses MV
  • Window: Sintered borosilicate glass , custom porosity on request.
  • Body: Stainless steel 304 / 316 housings; special alloys on request.

Typical specifications



Sintered Sight Glass — Specifications

Type Lumistar threaded sight glasses MV
Window material Sintered borosilicate glass
Body material Stainless steel 304 / 316
Temperature Up to 280C, choose the appropriate gasket according to the temperature
Pressure up to 6 bar (higher pressure device can becustomized),vacuum
Material certificates Certificate of conformity to EN 10204-3.1B or 3.1A
Components & typical materials
  • Guide nuts：Stainless steel 1.4301 (1.4307)
  • Gaskets：Klinger Sil C-4400 (or customer-specified gasket)
  • Glass：Borosilicate tempered glass (DIN 7080) — max ~280 °C or Soda-lime tempered glass (DIN 8902) — max ~150 °C;
  • O-rings：Viton, PTFE, Silicone rubber, EPDM (select per process)
  • Welded brackets：Stainless steel 1.4301 (1.4307) / 1.4404
  • Container / vessel wall：Customer / fabricator supplied
Combination & options

  • Compatible with Lumistar spotlights and sight-glass luminaires.

  • DN50 option: scraper model SW1 available.

  • DN125 option: spotlight + scraper combination available.

  • Glass types: soda-lime tempered (max ~150 °C) or borosilicate tempered (max ~280 °C).

  • O-ring/elastomer options: Viton, PTFE, silicone, EPDM.

  • Ring / bracket alloys: standard stainless steels and higher alloys available on request.

Need a custom porosity or diameter? Contact us for a quote.

Features & benefits

  • Designed for hygienic, sterile environments and CIP cleaning.

  • Weldable threaded brackets allow secure, leak-tight mount to vessel walls.

  • Multiple glass and gasket options to suit high temperatures and aggressive media.

  • Easy installation, service and replacement; compatible with spotlights and scraper accessories.

  • Long service life and low maintenance when specified correctly for the process.

Applications

  • Screwed sightglass fittings similar to DIN 11851.

  • Threaded brackets are weldable to vessel/container walls.

  • Suitable for sterile and hygienic applications — bioreactors, laboratory vessels, mixers, filters, tanks, agitators, separators and other closed vessels used in food, dairy, beverage, cosmetic and pharmaceutical plants.

Downloads

Lumistar threaded sight glasses MV — Datasheet (PDF):Lumistar threaded sight glasses MV
